Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,

Introducing the Beam Dye Machine, designed for desizing, bleaching, washing, and dyeing open-width textile cloth. Ideal for cotton, polyester, and blended textiles. Visit our factory for high-quality textile processing solutions.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
HR
Voltage
380V/50Hz 3phase Can Be Customized
Load Capacity
1000-2000kg
Certification
CE, ISO9001: 2000
Warranty
1 Year
Customized
Customized
Condition
New
Machine Item
Beam Dye Machine Is for Desizing, Bleaching,
Machine Painting Color
Be Made According to Your Need
Price
Lowest Reasonable Offers in The Market
After-Sales Service
24 Hours Technical Support by Email, Call, Video
Warranty Time
Offer Free Spare Parts and Service Within 12 Month
Working Experience
32 Years′ Experience
Delivery Date
Fast Delivery in 30 Days
Power(W)
45kw
Length of Tube
1200-2000mm
Steam Working Pressure
0.3MPa
Heating
Direct Steam/Indirect Steam
Dimension(L*W*H)
13860*2980*2650
Length of Hank
820mm
Max.Working Temperature
98 Degree
Transport Package
Standard Package or Nude Package Customized
Specification
Dimension(L*W*H): 13860*2980*2650
Trademark
HUARUI
Origin
Qingdao City
HS Code
8451290000
Production Capacity
100/Week

Product Description

Brief introduction:


Technical features:

Adopting AC frequency invert driving, PLC contorl and data communication technology.
Truly direct fabric surface tension, linear speed inspection and closed loop control.
Utilizing the touch screen technology. Excellent man-machine dialogue function.
Auto temperature control, auto direction reversing, auto stop and fabric swing function.
The dye liquor circulation system of the machine can make the temperature of the dye liquor be the same and make the dyestuffs be even distributed.Equipped with filtering device to prevent the blockage of the piping.
Heating protect device ensures the temperature rising speed to promote the production efficiency.
The entire machine is equipped with auxiliary devices such as overhead casing illumination lamp,breakage alarm lamp,emergency stop rod,etc.Safe operation,easy maintenance.
Water discharging valve,air chimney and fabric delivery
's crossbeam are controlled pneumatically.
The main components of this machine are imported to ensure the stability and reliability of this machine.
Full automatic control of the production can realize various kinds of technology combination.
The cover opening is flexible and convenient. The body can slide on the guiding rail smoothly.



Detail machine pictures, all photoes are for 100% real shooting ! For more pictures, video and details, please email me!
Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,

Specification

Diameter of main roller φ245-325mm
Max.diameter of cloth roll φ800-1200mm
Max.Working fabric width 1800-3400mm
Adjustable fabric rate 0-130m/min
Tension of fabrics 0-90kg


Control Function:

The whole machine is a double frequency conversion control system, man-machine operation interface .
Realize constant tension and constant linear speed setting.
Manual, automatic, acceleration, deceleration functions.
It has the functions of automatic head-turning, automatic track counting, automatic parking, and automatic lane full swing.
Automatic temperature control of the whole machine with process operation.
Operation screen programmable setting, process storage, automatic identification, automatic alarm.

Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,

Mainly for open width nylon,spandex, sllk, desizing, bleaching, scouring, dyeing, etc of fabric of cotton,polyester, flax and blended fabric.It can be widely used in the dyeing and printing industry to meet the requirement of small batches and different kinds.


Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,

OUR ADVANTAGES
1) Excellent, high corrosion-resistant stainless steel
2) Ultra-low bath ratio , Wisdom, energy saving and environmental protection
3) Humanized design Automatic lifting bracket
4) Automatic feeding system Precision feeding
5) Direct heating and indirect heating combined
6) Won the invention and utility model patent certificate


Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,

Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,
Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,

Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,

Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,


Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,
Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,
Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,
Beam Dye Machine Is for Desizing, Bleaching, Washing The Open-Width Textile Cloth as Well as Dyeing Open-Width Textile(Cotton<50%=, Polyester, Blended Textile,
